7.6.3
IH2: Input States
IH2 . ExBlo-I [Operation / Status Display / IH2]
Module input state: External blocking
7.6.4 IH2: Signals (Output States)
IH2 . Active [Operation / Status Display / All Actives]
[Operation / Status Display / IH2]
Signal: active
IH2 . Block. L1 [Operation / Status Display / IH2]
Signal: Inrush blocking of phase L1 of the phase overcurrent protection
IH2 . Block. L2 [Operation / Status Display / IH2]
Signal: Inrush blocking of phase L2 of the phase overcurrent protection
IH2 . Block. L3 [Operation / Status Display / IH2]
Signal: Inrush blocking of phase L3 of the phase overcurrent protection
IH2 . Block. Ph. [Operation / Status Display / IH2]
Signal: Inrush blocking of a phase of the phase overcurrent protection
IH2 . Block. 3-ph [Operation / Status Display / IH2]
Signal: 3-phase Inrush blocking: An inrush has been detected in (at least) one phase, so that all three phases are
blocked.
IH2 . Imax exceeded [Operation / Status Display / IH2]
Signal: The Inrush limit value has been exceeded, so that the inrush blocking has been cancelled.
IH2 . tmax elapsed [Operation / Status Display / IH2]
Signal: The (phase-selective) maximum duration of an inrush blocking has been reached, so that the inrush blocking
has been stopped.
34 WIC1 WIC1-1.0-EN-REF
7 Protection Parameter
7.6.3 IH2: Input States
