Seg WI Line WIC1 User Manual

Prot . SCmd ON [Protection Para / Breaker & Trip]
If: Device Variant/Inputs = Without Inputs
• “-”•
If: Device Variant/Inputs = Without Inputs
• “-”•
If: Device Variant/Inputs = Ext. Trip
•
“-”
•
If: Device Variant/Inputs = Ext. Trip, Ext. Reset
•
“-”
•
If: Device Variant/Inputs = Con󰊟gurable
• “-”, Prot . DI 1, Prot . DI 2•
If: Device Variant/Inputs = Con󰊟gurable Inputs
•
“-”, Prot . DI 1, Prot . DI 2
•
╚═▷
P.1
Switching ON Command, e.g. the state of the digital input
Prot . ExBlo TripCmd [Protection Para / Breaker & Trip]
“-” “-” . . . Prot . Pos OFF
╚═▷
P.1
If external blocking of the tripping command is activated (allowed), the tripping command of the entire device will be
blocked if the state of the assigned signal becomes true.
7.3
Prot: Direct Controls
Prot . Rst. LEDs, FIs, Flt.Scr. [Operation / Reset]
False False, True
╚═▷ True or not true
P.1
Direct Command to immediately reset all latched LEDs, all DiggiMEC Flag Indicators, and the Fault Info Screen that
might be visible on the DiggiMEC display.
Prot . Delete Fault Records [Operation / Reset]
False False, True
╚═▷ True or not true
P.1
Direct Command to immediately delete all entries from the Fault Recorder.
29WIC1WIC1-1.0-EN-REF
7 Protection Parameter
7.3 Prot: Direct Controls
