I2/I1> . ExBlo [Protection Para / I2/I1>]
“-” “-” . . . Prot . Pos OFF
╚═▷
P.1
External blocking of the module if the state of the assigned signal is true.
7.12.3
I2/I1>: Input States
I2/I1> . ExBlo-I [Operation / Status Display / I2/I1>]
Module input state: External blocking
7.12.4
I2/I1>: Signals (Output States)
I2/I1> . Active [Operation / Status Display / All Actives]
[Operation / Status Display / I2/I1>]
Signal: active
I2/I1> . Trip [Operation / Status Display / Trips]
[Operation / Status Display / I2/I1>]
Only available if:
• I2/I1> . Denition = Trip•
Signal: Trip
I2/I1> . Alarm [Operation / Status Display / Alarms]
[Operation / Status Display / I2/I1>]
Only available if:
• I2/I1> . Denition = Alarm•
Signal: Alarm
I2/I1> . Pickup [Operation / Status Display / Pickups]
[Operation / Status Display / I2/I1>]
Signal: Pickup
I2/I1> . IH2 Blo [Operation / Status Display / I2/I1>]
Signal: Blocking the trip command by an inrush
54 WIC1 WIC1-1.0-EN-REF
7 Protection Parameter
7.12.3 I2/I1>: Input States
