I>> . tChar [Protection Para / I>>]

0.1 0.05  . . .  10.00 P.1

Time multiplier/tripping characteristic factor. The setting range depends on the selected tripping curve.

I>> . tMin [Protection Para / I>>]

0.00s 0.00s  . . .  20.00s P.1

Minimum trip delay time. Independent of the measured current values, the trip delay time does never fall below the

minimum that is set here.

I>> . Reset Mode [Protection Para / I>>]

instantaneous instantaneous, de󰊟nite time, inverse time

╚═▷ Reset Mode

P.1

Reset Mode

I>> . tReset [Protection Para / I>>]

0.1s

Only available if:

• I>> . Reset Mode = de󰊟nite time•

0.00s  . . .  60.00s P.1

Reset delay for intermittent phase failures (INV characteristics only)

I>> . IH2 Blo [Protection Para / I>>]

Active Inactive, Active

╚═▷ Mode

P.1

Blocking the trip command, if an inrush is detected.

I>> . ExBlo [Protection Para / I>>]

“-” “-”  . . .  Prot . Pos OFF

╚═▷

P.1

External blocking of the module if the state of the assigned signal is true.

7.8.3

I>>: Input States

I>> . ExBlo-I [Operation / Status Display / I>>]

Module input state: External blocking

40 WIC1 WIC1-1.0-EN-REF

7 Protection Parameter

7.8.3 I>>: Input States

Seg WI Line WIC1 User Manual
