Prot . Force Trip Cmd [Service / Prot]

Inactive Inactive, Active

╚═▷ Mode

P.1

Direct Command to force the device to issue a trip command (for testing purposes). This has the following additional

e󰅯ects:

- The signals »Prot . Pickup«, »Prot . Trip« and »Prot . TripCmd« are set.

- A fault record is created.

- The breaker failure protection is triggered.

- An automatic reset is executed.

7.4

Prot: Input States

Prot . ExBlo TripCmd-I [Operation / Status Display / Prot]

Module input state: External Blocking of the Trip Command

7.5

Prot: Signals (Output States)

Prot . Active [Operation / Status Display / All Actives]
