7.13 I2> – Negative-Sequence Current Protection
7.13.1
I2>: Device Planning Parameters
I2> . Mode [Device planning / Projected Elements]
“-” “-”, use
╚═▷ Device planning
P.1
Unbalanced Load-Stage, general operation mode
I2> . Denition [Device planning / Denition]
Trip Trip, Alarm
╚═▷ Denition
P.1
Unbalanced Load-Stage: If set to “Alarm”: The function operates as a supervision function, i.e. a fault generates
neither alarm nor trip, but an »Alarm« signal gets issued instead. If set to “Trip”: The function operates as a
protection function, i.e. trips the breaker in case of a fault.
7.13.2
I2>: Settings
I2> . Function [Protection Para / I2>]
Active Inactive, Active
╚═▷ Mode
P.1
Permanent activation or deactivation of module/stage.
I2> . I2 [Protection Para / I2>]
0.2In 0.2In . . . 2.5In P.1
The Threshold setting denes a minimum operating current magnitude of I2 for the 46 function to operate, which
ensures that the relay has a solid basis for initiating a current unbalance trip. This is a supervisory function and not a
trip level.
I2> . Char [Protection Para / I2>]
DEFT DEFT . . . EF Curve
╚═▷ Char
P.1
Characteristic
I2> . t [Protection Para / I2>]
0.1s
Only available if:
• I2> . Char = DEFT•
0.00s . . . 300.00s P.1
Time delay for trip or alarm
