Page #56 background imageLoading...
Page #56 background image
I2> . tChar [Protection Para / I2>]
0.1
Only available if:
I2> . Char = IEC NINV
I2> . Char = IEC VINV
I2> . Char = IEC EINV
I2> . Char = IEC LINV
I2> . Char = RINV
I2> . Char = HV Fuse
I2> . Char = FR Fuse
I2> . Char = IEEE MINV
I2> . Char = IEEE VINV
I2> . Char = IEEE EINV
I2> . Char = EF Curve
0.05  . . .  10.00 P.1
Time multiplier/tripping characteristic factor. The setting range depends on the selected tripping curve.
I2> . tMin [Protection Para / I2>]
0.00s
Only available if:
I2> . Char = IEC NINV
I2> . Char = IEC VINV
I2> . Char = IEC EINV
I2> . Char = IEC LINV
I2> . Char = RINV
I2> . Char = HV Fuse
I2> . Char = FR Fuse
I2> . Char = IEEE MINV
I2> . Char = IEEE VINV
I2> . Char = IEEE EINV
I2> . Char = EF Curve
0.00s  . . .  20.00s P.1
Minimum trip delay time. Independent of the measured current values, the trip delay time does never fall below the
minimum that is set here.
56 WIC1 WIC1-1.0-EN-REF
7 Protection Parameter
7.13.2 I2>: Settings
