7.7.4
I>: Signals (Output States)
I> . Active [Operation / Status Display / All Actives]
[Operation / Status Display / I>]
Signal: active
I> . Trip [Operation / Status Display / Trips]
[Operation / Status Display / I>]
Only available if:
• I> . Denition = Trip•
Signal: Trip
I> . Alarm [Operation / Status Display / Alarms]
[Operation / Status Display / I>]
Only available if:
• I> . Denition = Alarm•
Signal: Alarm
I> . Pickup [Operation / Status Display / Pickups]
[Operation / Status Display / I>]
Signal: Pickup
I> . Trip IL1 [Operation / Status Display / I>]
Only available if:
• I> . Denition = Trip•
Signal: Trip due to a fault in phase L1
I> . Trip IL2 [Operation / Status Display / I>]
Only available if:
• I> . Denition = Trip•
Signal: Trip due to a fault in phase L2
I> . Trip IL3 [Operation / Status Display / I>]
Only available if:
• I> . Denition = Trip•
Signal: Trip due to a fault in phase L3
37WIC1WIC1-1.0-EN-REF
7 Protection Parameter
7.7.4 I>: Signals (Output States)
