Seg WI Line WIC1 User Manual

ExP[2] . Condition-I [Operation / Status Display / ExP[2]]
State of the module input: Condition for External Protection
7.18.4
ExP[2]: Signals (Output States)
ExP[2] . Active [Operation / Status Display / All Actives]
[Operation / Status Display / ExP[2]]
Signal: active
ExP[2] . Trip [Operation / Status Display / Trips]
[Operation / Status Display / ExP[2]]
Only available if:
• ExP[2] . De󰊟nition = Trip•
Signal: Trip
ExP[2] . Alarm [Operation / Status Display / Alarms]
[Operation / Status Display / ExP[2]]
Only available if:
• ExP[2] . De󰊟nition = Alarm•
Alarm
ExP[2] . Pickup [Operation / Status Display / Pickups]
[Operation / Status Display / ExP[2]]
Signal: Pickup
73WIC1WIC1-1.0-EN-REF
7 Protection Parameter
7.18.4 ExP[2]: Signals (Output States)
