Seg WI Line WIC1 User Manual

I2> . ExBlo [Protection Para / I2>]
“-” “-” . . . Prot . Pos OFF
╚═▷
P.1
External blocking of the module if the state of the assigned signal is true.
7.13.3
I2>: Input States
I2> . ExBlo-I [Operation / Status Display / I2>]
Module input state: External blocking
7.13.4
I2>: Signals (Output States)
I2> . Active [Operation / Status Display / All Actives]
[Operation / Status Display / I2>]
Signal: active
I2> . Trip [Operation / Status Display / Trips]
[Operation / Status Display / I2>]
Only available if:
• I2> . De󰊟nition = Trip•
Signal: Trip
I2> . Alarm [Operation / Status Display / Alarms]
[Operation / Status Display / I2>]
Only available if:
• I2> . De󰊟nition = Alarm•
Signal: Alarm
I2> . Pickup [Operation / Status Display / Pickups]
[Operation / Status Display / I2>]
Signal: Pickup
I2> . IH2 Blo [Operation / Status Display / I2>]
Signal: Blocking the trip command by an inrush
58 WIC1 WIC1-1.0-EN-REF
7 Protection Parameter
7.13.3 I2>: Input States
