I2> . Reset Mode [Protection Para / I2>]
instantaneous If: I2> . Char = DEFT
• instantaneous, de󰊟nite time•
If: I2> . Char = IEC NINV
• instantaneous, de󰊟nite time, inverse time•
If: I2> . Char = IEC VINV
•
instantaneous, de󰊟nite time, inverse time
•
If: I2> . Char = IEC EINV
•
instantaneous, de󰊟nite time, inverse time
•
If: I2> . Char = IEC LINV
• instantaneous, de󰊟nite time, inverse time•
If: I2> . Char = RINV
•
instantaneous, de󰊟nite time, inverse time
•
If: I2> . Char = HV Fuse
• instantaneous, de󰊟nite time•
If: I2> . Char = FR Fuse
•
instantaneous, de󰊟nite time
•
If: I2> . Char = IEEE MINV
•
instantaneous, de󰊟nite time, inverse time
•
If: I2> . Char = IEEE VINV
•
instantaneous, de󰊟nite time, inverse time
•
If: I2> . Char = IEEE EINV
•
instantaneous, de󰊟nite time, inverse time
•
If: I2> . Char = EF Curve
•
instantaneous, de󰊟nite time
•
╚═▷ Reset Mode
P.1
Reset Mode
I2> . tReset [Protection Para / I2>]
0.1s
Only available if:
• I2> . Reset Mode = de󰊟nite time•
0.00s . . . 60.00s P.1
Reset delay for intermittent phase failures (INV characteristics only)
I2> . IH2 Blo [Protection Para / I2>]
Active Inactive, Active
╚═▷ Mode
P.1
Blocking the trip command, if an inrush is detected.
57WIC1WIC1-1.0-EN-REF
7 Protection Parameter
7.13.2 I2>: Settings
