7.9.4
I>>>: Signals (Output States)
I>>> . Active [Operation / Status Display / All Actives]
[Operation / Status Display / I>>>]
Signal: active
I>>> . Trip [Operation / Status Display / Trips]
[Operation / Status Display / I>>>]
Only available if:
• I>>> . Denition = Trip•
Signal: Trip
I>>> . Alarm [Operation / Status Display / Alarms]
[Operation / Status Display / I>>>]
Only available if:
• I>>> . Denition = Alarm•
Signal: Alarm
I>>> . Pickup [Operation / Status Display / Pickups]
[Operation / Status Display / I>>>]
Signal: Pickup
I>>> . Trip IL1 [Operation / Status Display / I>>>]
Only available if:
• I>>> . Denition = Trip•
Signal: Trip due to a fault in phase L1
I>>> . Trip IL2 [Operation / Status Display / I>>>]
Only available if:
• I>>> . Denition = Trip•
Signal: Trip due to a fault in phase L2
I>>> . Trip IL3 [Operation / Status Display / I>>>]
Only available if:
• I>>> . Denition = Trip•
Signal: Trip due to a fault in phase L3
45WIC1WIC1-1.0-EN-REF
7 Protection Parameter
7.9.4 I>>>: Signals (Output States)
