Seg WI Line WIC1 User Manual

7.8.4
I>>: Signals (Output States)
I>> . Active [Operation / Status Display / All Actives]
[Operation / Status Display / I>>]
Signal: active
I>> . Trip [Operation / Status Display / Trips]
[Operation / Status Display / I>>]
Only available if:
• I>> . De󰊟nition = Trip•
Signal: Trip
I>> . Alarm [Operation / Status Display / Alarms]
[Operation / Status Display / I>>]
Only available if:
• I>> . De󰊟nition = Alarm•
Signal: Alarm
I>> . Pickup [Operation / Status Display / Pickups]
[Operation / Status Display / I>>]
Signal: Pickup
I>> . Trip IL1 [Operation / Status Display / I>>]
Only available if:
• I>> . De󰊟nition = Trip•
Signal: Trip due to a fault in phase L1
I>> . Trip IL2 [Operation / Status Display / I>>]
Only available if:
• I>> . De󰊟nition = Trip•
Signal: Trip due to a fault in phase L2
I>> . Trip IL3 [Operation / Status Display / I>>]
Only available if:
• I>> . De󰊟nition = Trip•
Signal: Trip due to a fault in phase L3
41WIC1WIC1-1.0-EN-REF
7 Protection Parameter
7.8.4 I>>: Signals (Output States)
