Seg WI Line WIC1 User Manual

7.15.3
Ipeak>: Input States
Ipeak> . ExBlo-I [Operation / Status Display / Ipeak>]
Module input state: External blocking
7.15.4 Ipeak>: Signals (Output States)
Ipeak> . Active [Operation / Status Display / All Actives]
[Operation / Status Display / Ipeak>]
Signal: active
Ipeak> . Trip [Operation / Status Display / Trips]
[Operation / Status Display / Ipeak>]
Only available if:
• Ipeak> . De󰊟nition = Trip•
Signal: Trip
Ipeak> . Alarm [Operation / Status Display / Alarms]
[Operation / Status Display / Ipeak>]
Only available if:
• Ipeak> . De󰊟nition = Alarm•
Signal: Alarm
Ipeak> . Pickup [Operation / Status Display / Pickups]
[Operation / Status Display / Ipeak>]
Signal: Pickup
Ipeak> . Trip IL1 [Operation / Status Display / Ipeak>]
Only available if:
• Ipeak> . De󰊟nition = Trip•
Signal: Trip due to a fault in phase L1
Ipeak> . Trip IL2 [Operation / Status Display / Ipeak>]
Only available if:
• Ipeak> . De󰊟nition = Trip•
Signal: Trip due to a fault in phase L2
63WIC1WIC1-1.0-EN-REF
7 Protection Parameter
7.15.3 Ipeak>: Input States
