Page #69 background imageLoading...
Page #69 background image
ExP[1] . Trigger Signal [Protection Para / ExP[1]]
If: Device Variant/Inputs = Without Inputs
“-”
If: Device Variant/Inputs = Without Inputs
“-”
If: Device Variant/Inputs = Ext. Trip
Prot . DI 2
If: Device Variant/Inputs = Ext. Trip, Ext. Reset
Prot . DI 2
If: Device Variant/Inputs = Con󰊟gurable
“-”, Prot . DI 1, Prot . DI 2
If: Device Variant/Inputs = Con󰊟gurable Inputs
“-”, Prot . DI 1, Prot . DI 2
╚═▷
P.1
Assign the trigger signal that will make the »ExP« module start (pickup).
ExP[1] . ExBlo [Protection Para / ExP[1]]
“-” “-”  . . .  Prot . Pos OFF
╚═▷
P.1
External blocking of the module if the state of the assigned signal is true.
7.17.3
ExP[1]: Input States
ExP[1] . ExBlo-I [Operation / Status Display / ExP[1]]
Module input state: External blocking
ExP[1] . Trigger Signal-I [Operation / Status Display / ExP[1]]
State of the module input: External trigger signal
7.17.4 ExP[1]: Signals (Output States)
ExP[1] . Active [Operation / Status Display / All Actives]
[Operation / Status Display / ExP[1]]
Signal: active
69WIC1WIC1-1.0-EN-REF
7 Protection Parameter
7.17.3 ExP[1]: Input States
