Latching Description
No latching No latching, the status always follows the status of the assigned signal.
With latching With latching, i.e. the state remains active once the the assigned signal has become
active. (After the assigned signal has dropped o the state can be reset by the device.)
Latching w. Auto-Reset With latching, i.e. the state remains active once the the assigned signal has become
active. In addition to a reset via DiggiMEC-HMI or via Digital Input there is also the
automatical reset permitted.
Color
Select the “active” color (if the assigned signal is active) and the “inactive” color (if the
assigned signal is inactive)
Selection list referenced by the following parameters:
• ╚═▷ DiggiMEC . LED2 Color•
Color Description
Red Red = “active” color (if the assigned signal is active)
Green Green = “active” color (if the assigned signal is active)
Green / Red Green = “active” color (if the assigned signal is active), red = “inactive” color (if the
assigned signal is inactive)
Selection list referenced by the following parameters:
• ╚═▷ Prot . Assign Ext. Reset•
•
╚═▷ Prot . Aux ON
•
• ╚═▷ Prot . Aux OFF•
• ╚═▷ Prot . SCmd ON•
• ╚═▷ ExP[1] . Trigger Signal•
• ╚═▷ ExP[2] . Trigger Signal•
Description
“-”
Prot . DI 1 Signal: Digital Input
Prot . DI 2 Signal: Digital Input
