Seg WI Line WIC1 User Manual

Prot . Assign Ext. Reset [Device Para / Reset]
If: Device Variant/Inputs = Without Inputs
• “-”•
If: Device Variant/Inputs = Without Inputs
• “-”•
If: Device Variant/Inputs = Ext. Trip
•
“-”
•
If: Device Variant/Inputs = Ext. Trip, Ext. Reset
•
Prot . DI 1
•
If: Device Variant/Inputs = Con󰊟gurable
• “-”, Prot . DI 1, Prot . DI 2•
If: Device Variant/Inputs = Con󰊟gurable Inputs
•
“-”, Prot . DI 1, Prot . DI 2
•
╚═▷
P.1
Assign an digital input signal that, when it becomes true, will reset all latched LEDs, all DiggiMEC Flag Indicators, and
a fault/trip info that might be visible on the DiggiMEC display.
Prot . Def. Autom. Reset [Device Para / Reset]
New Pickup or After 8 h OFF (=No Autom. Reset) . . . New Pickup or After 10 s
╚═▷ Def. Autom. Reset
P.1
The automatic reset will reset all latched LEDs, all DiggiMEC Flag Indicators, and a fault/trip info that might be visible
on the DiggiMEC display. This is done depending on this setting, when a new protection pickup occurs or after a
particular time has elapsed.
Prot . Meth.Detect.Bkr.Pos. [Protection Para / Breaker & Trip]
Current-Based If: Device Variant/Inputs = Without Inputs
• Current-Based•
If: Device Variant/Inputs = Without Inputs
• Current-Based•
If: Device Variant/Inputs = Ext. Trip
•
Current-Based
•
If: Device Variant/Inputs = Ext. Trip, Ext. Reset
•
Current-Based
•
If: Device Variant/Inputs = Con󰊟gurable
• Current-Based•
If: Device Variant/Inputs = Con󰊟gurable Inputs
•
Current-Based, Aux-Based, Current and Aux
•
╚═▷ Meth.Detect.Bkr.Pos.
P.1
Select the method to be used to determine the connected breaker position.
27WIC1WIC1-1.0-EN-REF
7 Protection Parameter
7.2 Prot: Settings
