Prot . Out. assign. [Device Para / WIC1 / Output]
Only available if:
Prot . Out. Mode ≠ Syst. O.K. &
Ext.Suppl.
If: Device Variant/Outputs = TC: TripCmd
“-”
If: Device Variant/Outputs = TC: TripCmd, FI: TripCmd
Prot . TripCmd
If: Device Variant/Outputs = TC: TripCmd, FI: con󰊟gurable
“-”  . . .  Prot . Pos OFF
╚═▷
P.1
Assign the signal that shall activate the output.
(If the output is set as impulse output the signal triggers the impulses for the connected Flag Indicator. If it is set as
relay output the signal sets it to the “active” state.)
Prot . Out. Inverting [Device Para / WIC1 / Output]
Inactive
Only available if:
Prot . Out. Mode ≠ Syst. O.K. &
Ext.Suppl.
Inactive, Active
╚═▷ Mode
P.1
Inverting of the signal that has been assigned to the output.
Prot . Nom voltage [Device Para / WIC1 / Digital Inputs]
If: Dual-Powered Device Variant = True
24 VDC, 48 VDC ... 60 VDC, 110 VDC, 230 VDC, 110 VAC, 230
VAC
If: Dual-Powered Device Variant = False
115 VAC / 230 VAC
╚═▷ Nom voltage
P.1
Nominal voltage of the digital inputs
26 WIC1 WIC1-1.0-EN-REF
7 Protection Parameter
7.2 Prot: Settings
