Description
SOTF . Pickup Signal: Pickup
ExP[1] . Trip Signal: Trip
ExP[1] . Alarm Alarm
ExP[1] . Pickup Signal: Pickup
ExP[2] . Trip Signal: Trip
ExP[2] . Alarm Alarm
ExP[2] . Pickup Signal: Pickup
TCM . Alarm Signal: Alarm
CBF . Alarm Signal: Alarm
System . New error/warning Signal: A new Self-Supervision message (error or warning) has been issued.
System . Prot. Ready Signal: The device has completely booted, all protection functions are running and there
is enough electrical energy for a trip pulse.
System . Intern.Volt. not OK Signal: The self-supervision of the device has determined a problem with the internal
voltage level or energy supply. This might impair the overall protection functionality,
including the possibility to output a trip pulse. (If the supply via the connected CTs is
sucient you might want to check for a potential energy drain through the devices
connected to the output(s).)
Prot . TripCmd Signal: Trip Command
Prot . Trip Signal: General Trip
Prot . Alarm Signal: General Alarm
Prot . Pickup Signal: General Pickup
Prot . Trip IPh Signal: General Trip due to a phase current fault
Prot . Trip IG Signal: General Trip due to a ground current fault
Prot . Trip Ext. Signal: General Trip due to an external signal
Prot . Trip IL1 Signal: General Trip due to a fault in phase L1
Prot . Trip IL2 Signal: General Trip due to a fault in phase L2
Prot . Trip IL3 Signal: General Trip due to a fault in phase L3
Prot . Pickup I Ph Signal: General Pickup due to a phase current fault
Prot . Pickup IG Signal: General Pickup due to a ground current fault
Prot . Pickup Ext. Signal: General Pickup due to an external signal
Prot . DI 1 Signal: Digital Input
Prot . DI 2 Signal: Digital Input
Prot . Pos ON Signal: Circuit Breaker is in ON-Position
Prot . Pos OFF Signal: Circuit Breaker is in OFF-Position
Nom voltage
Nominal voltage of the digital inputs
Selection list referenced by the following parameters:
89WIC1WIC1-1.0-EN-REF
11 Selection Lists
