• ╚═▷ Prot . Nom voltage•
Nom voltage Description
24 VDC 24 VDC
48 VDC ... 60 VDC 48 VDC ... 60 VDC
110 VDC 110 VDC
230 VDC 230 VDC
110 VAC 110 VAC
230 VAC 230 VAC
115 VAC / 230 VAC 115 VAC / 230 VAC (depending on the input)
Preference for Operation
If set to “Early wake-up”, the DiggiMEC is fully available at smaller primary currents,
but at the cost of more inaccurate WIC1 measurement values. If set to “Precise meas.”,
the DiggiMEC gets fully available only with higher primary currents, but the WIC1
measurement values will be more precise. In general, it is recommended to keep the
default “Precise meas.”.
Selection list referenced by the following parameters:
• ╚═▷ DiggiMEC . Preference for Operation•
Preference for Operation Description
Precise meas. With this setting, the DiggiMEC gets fully available only with higher primary currents,
but the WIC1 measurement values will be more precise.
Early wake-up With this setting, the DiggiMEC is fully available at smaller primary currents, but at
the cost of more inaccurate WIC1 measurement values. If set to “Precise meas.”, the
DiggiMEC gets fully available only with higher primary currents, but the WIC
Latching
Activates/deactivates latching and the type of automatical reset of the latching.
Selection list referenced by the following parameters:
• ╚═▷ DiggiMEC . FI / BO 1 latching•
• ╚═▷ DiggiMEC . FI / BO 2 latching•
• ╚═▷ DiggiMEC . FI / BO 3 latching•
•
╚═▷ DiggiMEC . LED2 latching
•
• ╚═▷ DiggiMEC . LED3 latching•
90 WIC1 WIC1-1.0-EN-REF
11 Selection Lists
