Seg WI Line WIC1 User Manual

Prot . I ON [Protection Para / Breaker & Trip]
0.10In 0.05In . . . 0.20In P.1
The breaker is determined as ON (closed) based on current measurement if any phase current is greater than this
value (for at least the settable duration »t ON/OFF«).
Prot . Aux ON [Protection Para / Breaker & Trip]
If: Device Variant/Inputs = Without Inputs
• “-”•
If: Device Variant/Inputs = Without Inputs
• “-”•
If: Device Variant/Inputs = Ext. Trip
•
“-”
•
If: Device Variant/Inputs = Ext. Trip, Ext. Reset
•
“-”
•
If: Device Variant/Inputs = Con󰊟gurable
• “-”•
If: Device Variant/Inputs = Con󰊟gurable Inputs
•
“-”, Prot . DI 1, Prot . DI 2
•
╚═▷
P.1
The CB is in ON-position if the state of the assigned signal is true (52a).
Prot . Aux OFF [Protection Para / Breaker & Trip]
If: Device Variant/Inputs = Without Inputs
• “-”•
If: Device Variant/Inputs = Without Inputs
• “-”•
If: Device Variant/Inputs = Ext. Trip
•
“-”
•
If: Device Variant/Inputs = Ext. Trip, Ext. Reset
•
“-”
•
If: Device Variant/Inputs = Con󰊟gurable
• “-”•
If: Device Variant/Inputs = Con󰊟gurable Inputs
•
“-”, Prot . DI 1, Prot . DI 2
•
╚═▷
P.1
The CB is in OFF-position if the state of the assigned signal is true (52b).
28 WIC1 WIC1-1.0-EN-REF
7 Protection Parameter
7.2 Prot: Settings
