CT Type Description
Relative Phase current values are displayed as relative values.
WE2 : 16 A ... 56 A Phase current values are displayed as primary values, that are calculated based on the
connected CT type with primary current range 16 A ... 56 A.
W2 : 16 A ... 56 A Phase current values are displayed as primary values, that are calculated based on the
connected CT type with primary current range 16 A ... 56 A.
W3 : 32 A ... 112 A Phase current values are displayed as primary values, that are calculated based on the
connected CT type with primary current range 32 A ... 112 A.
W4 : 64 A ... 224 A Phase current values are displayed as primary values, that are calculated based on the
connected CT type with primary current range 64 A ... 224 A.
W5 : 128 A ... 448 A Phase current values are displayed as primary values, that are calculated based on the
connected CT type with primary current range 128 A ... 448 A.
W6 : 256 A ... 896 A Phase current values are displayed as primary values, that are calculated based on the
connected CT type with primary current range 256 A ... 896 A.
Polarity
Selection list referenced by the following parameters:
• ╚═▷ CT . CT Shift by 0°/180°•
• ╚═▷ CT . ECT Shift by 0°/180°•
Polarity Description
0 0
180 180 degree polarity correction (wiring faults)
Meth.Detect.Bkr.Pos.
Select the method to be used to determine the connected breaker position.
Selection list referenced by the following parameters:
• ╚═▷ Prot . Meth.Detect.Bkr.Pos.•
Meth.Detect.Bkr.Pos. Description
Current-Based The breaker position is determined based on current measurement.
Aux-Based The breaker position is dependent on a particular input signal (Aux contacts 52a/52b of
the circuit breaker).
Current and Aux The breaker position is determined based on current measurement AND input signal
(Aux contacts 52a/52b of the circuit breaker).
