Prot . Trip IPh [Operation / Status Display / Prot]
Signal: General Trip due to a phase current fault
Prot . Trip IG [Operation / Status Display / Prot]
Signal: General Trip due to a ground current fault
Prot . Trip Ext. [Operation / Status Display / Prot]
Avail. depends on device type.
Signal: General Trip due to an external signal
Prot . Trip IL1 [Operation / Status Display / Prot]
Signal: General Trip due to a fault in phase L1
Prot . Trip IL2 [Operation / Status Display / Prot]
Signal: General Trip due to a fault in phase L2
Prot . Trip IL3 [Operation / Status Display / Prot]
Signal: General Trip due to a fault in phase L3
Prot . Pickup I Ph [Operation / Status Display / Prot]
Signal: General Pickup due to a phase current fault
Prot . Pickup IG [Operation / Status Display / Prot]
Signal: General Pickup due to a ground current fault
Prot . Pickup Ext. [Operation / Status Display / Prot]
Avail. depends on device type.
Signal: General Pickup due to an external signal
Prot . Pickup IL1 [Operation / Status Display / Prot]
Signal: General Pickup due to a fault in phase L1
Prot . Pickup IL2 [Operation / Status Display / Prot]
Signal: General Pickup due to a fault in phase L2
Prot . Pickup IL3 [Operation / Status Display / Prot]
Signal: General Pickup due to a fault in phase L3
31WIC1WIC1-1.0-EN-REF
7 Protection Parameter
7.5 Prot: Signals (Output States)
