Prot . Pos ON [Operation / Status Display / Prot]
Signal: Circuit Breaker is in ON-Position
Prot . Pos OFF [Operation / Status Display / Prot]
Signal: Circuit Breaker is in OFF-Position
Prot . ON Cmd [Operation / Status Display / Prot]
Signal: ON command issued to the breaker
Prot . Syst. O.K. & Ext.Suppl. [Operation / Status Display / Prot]
Avail. depends on device type.
Signal: The WIC1 is running and is supplied by external auxiliary power and has loaded sucient electrical energy for
triggering the trip impulse output.
Prot . - Not in menu tree, only: Event recorder
none
Prot . DI 1
Prot . DI 2
[Operation / Status Display / Prot]
Avail. depends on device type.
Signal: Digital Input
32 WIC1 WIC1-1.0-EN-REF
7 Protection Parameter
7.5 Prot: Signals (Output States)
