CONTROLLER UNIT
53
10
2
Disconnect the related harnessing
1
With the power OFF. Unlock and remove the Door Back Lower
10-1-2 - Removing the "Pull-It" Control Unit
3
Remove the (4) ange nuts on the xings highlighted and remove the assembly
