Sega Racing Classic - Switch Unit

32
EXPLANATION OF TEST AND DATA DISPLAY
9-1 SWITCH UNIT
Becarefulthatangerorhanddoesnotgetcaughtwhenopening/closingthe
door.
●Adjust
thesoundtotheoptimumvolume,takingintoconsiderationthe
environmentalrequirementsoftheinstallationlocation.
●Removingthecoinmetercircuitryrendersthegameinoperable.
Unlock and open the coin chute door. Inside is a switch unit.
Switch Unit
TEST Button
(TEST)
Establishes TEST MODE. Becomes the button to conrm selections in TEST
MODE.
SERVICE Button
(SERVICE)
Makes it possible to enter credits for service without increasing the coin meter.
Becomes the button to select items in TEST MODE.
Sound Volume Knob
(SOUND VOLUME)
This is the volume knob for speakers at the left and right of the control panel.
Turn the knob to the right to increase speaker volume.
