164
MAINTENANCE
NOTICE
Due to the continuous upgrading of products, the fuse
may have slight changes. All functional positions and
specifications in the fuse box are subject to the actual
product
。
F20 Coil 10A
F21 The main fuse 30A or 50A
F22 EPS 50A
R1
2WD/4WD relay 1 12V 20A
R2 DTS relay 12V 20A
R3 IG relay 12V 20A
R4 Main relay 12V 20A
R5
2WD/4WD relay 2 12V 20A
R6
ECU-4WD relay
(optional equipment)
12V 20A
R7 Lower beam relay 12V 20A
R8 High beam relay 12V 20A
R9 Auxiliary starting relay 12V 20A
R10 Day light relay 12V 20A
R11
Fuel pump relay 12V 20A
R12
Fan relay 12V 20A
