64
MAINTENANCE
HANDLEBAR ADJUSTMENT
The handlebars can be adjusted to suit the rider's angle.
!
WARNING
Improper adjustment of the handles or improper torque
of tightening bolts can result in limited or loose of handler
steering, loss of control can result in severe injury or death.
Always follow the adjustment procedure, or check out the
services at your dealer.
1
M8×48 (4 PC)
1. Loosen the four handlebar bolts.
2. Adjust the position of the handlebar according to the
rider needs.
3. Tighten the two front bolts, and then tighten the two
rear bolts. Leave a gap of 1/8 (3 mm) at the back of the
clamp block.
4. Tighten the fastening bolts.
To Next Page
