87
OPERA
TION
Maximum loading cap
acity
Don’t o
ver the maximum loading c
apacity
。
V
ehicle Model
SGW570F-A3
SGW570F-A6
Front Shelf
Front Shelf
40KG
40KG
40KG
40KG
Rear Shelf
Rear Shelf
60KG
60KG
60KG
60KG
Maximum
Maximum
traction
traction
Horizontal
Horizontal
300KG
300KG
350KG
350KG
V
ertical
V
ertical
100KG
100KG
100KG
100KG
92
94
Table of Contents
Table of Contents
3
Table of Contents
7
Safety Introduction
7
Warning Labels
9
Special Safety Messages
16
Important Safety Information
20
Reading the Manual
20
Safe Driving Age
21
Riding Equipment
22
Using Alcohol or Drugs
24
Vehicle Modification
25
Passengers
26
Contact with Exhaust
27
Fuel Safety
28
Table of Contents
29
Vehicle Device
29
Vehicle Activation
31
Vehicle Unlocked
33
App Function
34
Parts and Control
35
Parts Localization
35
Handlebar Switch
36
Ignition Lock
37
Engine Start/Stop Switch
38
The Headlight Switch
39
Left Right Steering Switch
40
Emergency Switch
41
Force-Multiplier Switch
42
Winch Switch
43
Four-Wheel Drive
44
Toggle Switch for Two-Wheel Drive or
44
Accelerator
46
Standby Power Output Seat
47
Shift Institutions
48
Parking Brake
49
Parking Brake Lever Free Clearance
50
Foot Brake
51
Auxiliary Brake
53
Fuel Tank Cap
54
Storage Box
55
Instrument Parts
56
Instrument Indicator Light/Warning Light
57
Instrument Information Display Area
60
Diagnostic Displays Code Definitions
63
Screen Function Setting
69
Handlebar Adjustment
70
Operationoperation
71
Operation
71
Basic Drving Guide
73
Trail Etiquette
73
Brake System Run-In
74
Know Your Riding Area/Tread Lightly
74
Vehicle Run-In-Period
74
Clutch/Belt
75
New Operator Driving Procedures
75
Park the Vehicle
76
Starting the Vehicle
76
Turning the Vehicle
76
Driving in Reverse
77
Turning Around on a Hill (K-Turn)
78
Driving on Slippery Surfaces
79
Driving through Water
80
Driving over Obstacles
81
Driving Uphill
82
Driving Downhill
84
Driving on a Sidehill
85
Parking on an Incline
86
Braking
87
Parking the Vehicle
87
Break-In Guidelines
88
Inspection Items
89
Pre-Ride Inspection
89
Load Limits & Guidelines
91
Maximum Loading Capacity
93
Loading Guidelines
94
Trailer
95
Winch Operation
97
Maintenance
103
Regular Maintenance
107
Periodic Maintenance Table
108
Lubricating Oil
113
Seat Cushion Remove
114
Tank Cover
115
Cover
116
Remove Lower Cover of Instrument
117
Engine Oil Maintenance Program
118
Oil Recommendation
119
Engine Oil Level Check
120
Changing Engine Oil and Filter
122
Drain the Engine Oil
123
Oil Strainer Clean
124
Oil Filter Change
125
Front/Rear Gear Box Liquid
127
Front/Rear Axle Gear Oil
128
Adding Coolant
130
Coolant
130
Brake System
132
Brake Oil
133
Front Brake Fluid
135
Brake Component
136
Tire
137
Tire Pressure
137
Tread Depth of Tire
138
Replace the Tires
139
Wheel Component Removal
139
Tire Replacement
141
Oil Shock Absorber
142
Shock Absorber Adjustment
142
Adjustable Shock Absorber
143
Suspension Drive Lubrication
145
Drvetrain Boots
146
Air Filter
147
Change the Headlight
149
Lamp
149
Replace Taillight/Rear Turn Light
152
High Beam Adjustment
153
Spark Plug
156
Spark Plug Inspection
157
Spark Arrester
159
Battery
161
Battery Disassembly
162
Battery Charging
163
Battery Installation
165
Fuse
166
Fuse Box
167
Fuse/Relay Distribution and Rated Amperage
168
Fuse Box Replacement
171
Appearance Care
172
Cleaning Vehicles
173
Vehicle Storage
173
Specifications
174
Troubleshooting
182
Drive Belt and Cover Problems
183
Engine Doesn't Turn over
186
Engine Pings or Knocks
186
Engine Stops or Loses Power
187
Engine Turns Over, Fails to Start
187
Engine Backfires
188
Engine Runs Irregularly, Stalls or Misfires
189
Engine Stops or Loses Power
191
Emission Control System
192
Exhaust Emission Control System
193
Source of Exhaust Emissions
193
Crankcase Emission Control System
194
Noise Control System
194
Warranty
195
Limited Warranty
196
Registration
196
Exclusions-Are Not Warranted
197
Limitations of Warranties and Remedies
198
Maintenance Log
201
