52
VEHICLE DEVICE
Item Legend Functional specifi cations
1 Turn Left
This light is lit when the left turn
signal is turned on
2 High Beam
This lamp illuminates when the
headlamp switch is set to high
beam.
3 Position
indicator
The front light, tail light, license
plate light and instrument panel
light are on
4 Check
Engine
This indicator appears if an
EFI-related fault occurs. Do
not operate the vehicle if this
warning appears. Serious engine
damage could result.
5 Oil Pressure
Warning
This light is on when oil pressure
is too low.
6 Fuel level
The lamp lights up when the fuel
level is too low
7 Coolant
temperature
warning lamp
Indicator light showing excessive
temperature of engine coolant.
When it lights up and alarms,
the engine should be stopped
immediately and shut down.
After cooling down to normal
temperature, the engine should
continue to run
Indicator light/warning indication
