90
OPERATION
NOTICE
The speed must be less than 15 km/h during towing.
Improper use of hooks or exceeding the maximum towing
weight capacity may cause serious damage to your vehicle.
In this case, your ATV will not be covered by service policy.
Do not install trailers larger than 4 inches (10 cm). Never
install vehicle accessories on the ATV. Always install
accessories approved (or equivalent) designed for ATV use.
boltbolt
2-M82-M8
×2020
nutnut M20M20
springspring washerwasherφ2020
cottercotter pinpin bracketbracket
NutNut M8M8
trailertrailer ballball
trailertrailer ballball
bracketbracket
pinpin shaftshaft
boltbolt 2-M82-M8×4545
boltbolt
2-M82-M8
×2020
towingtowing bracketbracket
FrameFrame
E1313
55R-0155R-01 47034703
