Section 1: Introduction
Valve System
2016 Bambi MAX Service Manual – Models 1518-3542 (Version E) 5
We Engineer Solutions
The controller has an internal motor protection system to prevent the motor from being overloaded. When
excessive current flows to the motor due to a stalled condition, the motor protection device activates.
When activated, the device isolates the motor from the power source. but does not remove power from the
rest of the controller. The controller and valve will remain locked in whatever state they were at the time
the motor protection device was activated.
To reset the motor protection, turn off power to the circuit using the aircraft's circuit breaker. Wait for
approximately 10 seconds and turn the power back on again. The valve should return to its normally closed
state.
