Section 8: Repair Quick Guide
IDS Hub Repair Criteria
2016 Bambi MAX Service Manual – Models 1518-3542 (Version E) 49
We Engineer Solutions
IDS Hub Repair Criteria
• Cracks or breaks across the major section of the IDS hub.
• Two or more broken or cracked spoke brackets.
• Two or more broken or missing spokes, clevis pins, shell brackets.
• Three or more bent spokes (bends in excess of 20 degrees = broken).
• One broken or cracked spoke bracket on IDS hub.
• One broken or missing spoke.
• One broken or missing clevis pin or shell bracket.
• Up to two bent spokes.
• Wear on IDS hub.
• Dents, abrasions and wear on spokes.
• Clevis pin and shell bracket wear.
Category 1: Safety
Cease operations and repair immediately.
Category 2: Operational
Repair before next days operation or eight hours flight time.
Category 3: Monitor
Monitor and/or repair if condition deteriorates.
Category 4: Okay
Does not need repair.
