SEI Industries BAMBI MAX - Bambi MAX Valve 16 Lift Bar

Section 10: Specifications and Parts
Parts Listings
2016 Bambi MAX Service Manual – Models 1518-3542 (Version E) 82
We Engineer Solutions
Bambi MAX Valve 16" Lift Bar
ITEM
MODEL
PART NUMBER
DESCRIPTION QTY
1 000233 BAR, LIFT, 16” 1
2 000236 BUSHING, GUIDE, 16” 2
3 001619 RETAINER, CABLE 1
4 001615 CABLE, DRIVE, ASSEMBLY 1
5 000012 BOLT, HX, 10-32 x 1-17/32”, CAD 4
6 001606 SCREW, 10-24 X 3/4", HXSL, SS 2
7 001848 WASHER, LOCK, SPLIT, #10, SS 2
8 001843 WASHER, FLAT, 0.20 x 0.50 x 0.6, SS
4
9
BBX1518
–
BBX3542
001685 NUT, HX, NYLOCK, 10-32, SS 4
