SEI Industries BAMBI MAX - IDS System, Models 2024-3542 (Continued)

Section 10: Specifications and Parts
Parts Listings
2016 Bambi MAX Service Manual – Models 1518-3542 (Version E) 93
We Engineer Solutions
IDS System, Models 2024-3542 (continued)
ITEM
MODEL PART # DESCRIPTION QTY
ALL 005373 HUB 8 SPOKE 1
BBX2024 005374
BBX2226 007224
BBX2732 005376
1
BBX3542 005377
HUB W/ Deployment and Restrainer Cables 1
BBX2024
BBX2024S
005343 SPOKE, TUBE, 16-3/4”
BBX2226 005344 SPOKE, TUBE, 19-3/8”
BBX2732
BBX2732S
005345 SPOKE, TUBE, 20”
2
BBX3542 005346 SPOKE, TUBE, 21-5/8”
8
3 005385 BRACKET, SHELL 8
4 005389 PATCH,W EAR, BRACKET 8
5
ALL
004848 BRACKET, RESTRAINER 2
BBX2024
BBX2024S
BBX2226
005297
BBX2732
BBX2732S
005298
6
BBX3542 005299
CABLE, IDS, RESTRAINER 2
BBX2024 005316
BBX2024S
BBX2226
006477
BBX2732 005317
BBX2732S
008828
7
BBX3542 005317
CABLE, IDS, DEPLOYMENT
1
8 000496 SCREW,10-24 X 7/8, PNPH, SS 8
9 000497 SCREW,10-24 X 1”, PNPH, SS 12
10 001856 WASHER, FLAT,3/16 X 1, FND, SS 20
11 001833 WASHER, FLAT,1/4 X 11/16, THIN, SS 2
12 001824 WASHER, 3/16 X 1 X 1/8 NEO 2
13 000068 WASHER, FLAT,5/16 X 3/4, SS 16
14 001826 WASHER, 5/16 X 1 X 1/8, NEO 16
15 001660 NUT, HX, NYLOCK,10-24, SS 20
16 001697 PIN, CLEVIS, 5/16 X 1-3/4, SS 16
17 001703 PIN, CLEVIS, 1/4 1-1/8, SS 2
18 001710 PIN, COTTER, 1/16 X 3/4 PLT 2
19
ALL
001713 PIN, COTTER, 3/32 X 3/4 PLT 16
