Section 10: Specifications and Parts
Parts Listings
2016 Bambi MAX Service Manual Models 1518-3542 (Version E) 96
We Engineer Solutions
Ballast Systems, Models 1821-3542 (continued)
ITEM
MODEL PART # DESCRIPTION QTY
BBX1821 005444
BBX2024
BBX2024S
BBX2024PF
BBX2226
BBX2226PF
005452
BBX2732
BBX2732S
005446
1
BBX3542 005447
POUCH, BALLAST 1
2 005465 BAR, BALLAST, SQUARE,2X2X8.375, GALV 1
3 005466 BAR, BALLAST, TAPER,2X2X8.375 GALV 2
4 003001 QUICKLINK, 1/4, ZC-PLT 3
5 000370 BOLT, HX, 1/4-20 X 1, SS 2
6 001857 WASHER, FLAT,1/4 X 1-1/2,FND, SS 4
7 001828 WASHER, 7/32 X 1-1/2 X 1/8 NEO 2
8 001662 NUT, HX, NYLOCK,1/4-20, SS 2
9 000493 SCREW, 10-24 X 1/2,PNPH, SS 4
10 001855 WASHER, FLAT, #10 X 3/4,FND, SS 8
11
ALL
001660 NUT,HX, NYLOCK,10-24, SS 4
BBX1821 006185
BBX2024
BBX2024S
BBX2024PF
BBX2226
BBX2226PF
006186
BBX2732
BBX2732S
006187
KIT
BBX3542 006188
BALLAST, POUCH, ASSEMBLY, COMPLETE
1
