Filter Basket Assembly (continued)
ITEM
MODEL
PART # DESCRIPTION QTY
1
ALL
005208 BASKET, FILTER, PF2 1
2 001087 BRACKET, MOUNT, FILTERBASKET, PF2 3
3 001088 BLOCK, BUMPER, PUMP, PF2 1
4 001652 SPACER, 1/4” x 5/8” NYLON 4
5 000369 BOLT, HEX, 1/4-20 x 3/4, SS 6
6 000370 BOLT, HEX, 1/4-20 x 1, SS 2
7 000376 BOLT, HEX, 1/4-20 x 1-1/2, SS 4
8 000388 BOLT, HEX, 5/16-18 x 1-1/2, SS 3
9 001838 WASHER, FLAT, 0.27 x 0.50 x 0.032, SS 4
10 001833 WASHER, FLAT, 0.28 x 0.69 x 0.036, SS 14
11 001834 WASHER, FLAT, 0.28 x 0.75 x 0.125, SS 4
12 001858 WASHER, FLAT, 0.28 x 1.00 x 0.047, SS 4
13 001662 NUT, HEX, NYLOCK, 1/4-20, SS 12
14
2024
003844 CHAIN, 3/16”, GR30, GLV.
2.6 FT
2226 2.6 FT
2732 3.0 FT
3542 3.7 FT
4453 4.0 FT
5566 4.3 FT
15 ALL 001788 SHACKLE, ANCHOR, SCREW, 1/4, GLV 2
