Section 10: Specifications and Parts
Parts Listings
2016 Bambi MAX Service Manual Models 1518-3542 (Version E) 101
We Engineer Solutions
Motor Assembly (continued)
ITEM
PART #
DESCRIPTION QTY
1 006230 MOTOR, PF2, ASSEMBLY 1
2 001059 CUP, SEAL, MOTOR 1
3 005207 ADAPTER, MOTOR, PF2 1
4 005734 IMPELLER, CAST, SS, 4”, #3 1
5 002957 CLAMP, CABLE, 5/8” 1
6 005175 FITTING, GREASE, 1/4-28 x 15/16 1
7 007995 O-RING, BUNA N, #011, 50A 2
8 001890 O-RING, BUNA N, #124 1
9 001866 STATOSEAL, 5/16,PLT 2
10 006228 SEAL, LIP, 5/8 x 25 x 1/4 1
11 000369 BOLT, HEX, 1/4-20 x 3/4, SS 1
12 000533 BOLT, HEX, 1/4-28 x 3/4, SS 1
13 000432 SCREW, SC, 5/16-18 x 1, SS 2
14 001852 WASHER, LOCK, SPLIT, 1/4, SS 1
15 001838 WASHER, FLAT, 0.27 x 0.50 x 0.032, SS
2
16 001833 WASHER, FLAT, 0.28 x 0.69 x 0.036, SS
1
17 001834 WASHER, FLAT, 0.28 x 0.75 x 1.125, SS
1
18 001662 NUT, HEX, NYLOCK, 1/4-20, SS 1
19 001734 PIN, SPLIT, 1/8 x 3/8, SS 1
