Discharge Hose Assembly (continued)
ITEM MODEL PART # DESCRIPTION QTY
2024
2226
001079 HOSE, DISCHARGE, PF2, 2024-2226
2732 001081 HOSE, DISCHARGE, PF2, 2732
1
3542 001082 HOSE, DISCHARGE, PF2, 3542
1
2 006231 ELBOW, PF2, FABRICATION 1
3 006413 CONE, SEGMENT, PLASTIC 2
4 003060 CLAMP, T-BOLT, 4.5”, SS 2
5 006516 SCREW, SC 5/16-18 x 2, SS 2
6 006702 WASHER, FLAT. 0.34 x 0.69 x 0.08, SS 4
7
ALL
001664 NUT, HEX, NYLOCK, 5/16-18, SS 7
