Section 4: Making Adjustments
Adjusting Components
2016 Bambi MAX Service Manual – Models 1518-3542 (Version E) 19
We Engineer Solutions
• Notice particularly the location of the 9 o'clock hole with respect to the cable anchor
block. It is helpful to draw a reference line on the sensor cam to a reference point on the
anchor block.
• Loosen the set screw on the sensor cam using a 3/32 hex key.
• If the valve is too low, adjust the valve upwards by rotating the sensor cam counter-
clockwise so that your reference line moves approximately 1/16." Tighten the set
screw.
• If the valve is too high, adjust the valve downwards by rotating the sensor cam
clockwise so that your reference line moves approximately 1/16" (1 mm). Tighten one
set screw.
• After adjustment, power up the bucket circuit.
• The valve should move to the closed position.
• The indicator light should have a steady yellow color.
• The cable drum / sensor cam should not oscillate.
• Actuate the bucket dump switch and hold
• The valve should move to the open position.
• The indicator light should have a steady green colour.
• The cable drum / sensor cam should not oscillate.
• Release the dump switch to allow the valve to close.
• Re-adjust the valve as necessary until the correct open and close conditions are met.
• Check to see if set screw is tight.
• Note the position of the reference line or draw a new line at the correctly adjusted
position.
