Selco M4200 - Open Collector Outputs; Normally De-energized; Normally Energized; Load Capacity

M4200 - User manual
Revision: 07.03.2017 Page 9
Load capacity
The output relays are able to manage any kind of resistive load. The load capacity depends on whether AC
or DC voltage is connected to the relay.
Below is listed the maximum load capacity for AC and DC voltage respectively:
Max. AC load:
250VAC / 4A
Max. DC load:
Readings of DC load
capacity curve above:
VDC
Ampere
10
4
12
4
24
4
48
2
110
0,5
300
0,1
