Selco M4200 - Input and General Settings

M4200 - User manual
Revision: 07.03.2017 Page 17
Dip switch - programming
This section lists all possible settings that can be done by the switches on the rear of the alarm monitor.
Before starting the programming session please read the previous section Dip switches - operational
principle on page 15.
Input settings
Before programming the input settings please select the position number on the rotary switch (position 1 - 8).
In the table below the default settings are marked with bold type.
Switch row 1
Function
Switch setting
Switch setting
Switch setting
Description
Input type
SW1.1
OFF
Normally Open
ON
Normally Closed
Input reference
SW1.2
OFF
GND
ON
+VREF OUT
Cable monitoring
SW1.3
OFF
Inactive
ON
Active
Input Delay
SW1.4
SW1.5
SW1.6
OFF
OFF
OFF
25 ms
OFF
OFF
ON
500 ms
OFF
ON
OFF
1 s
OFF
ON
ON
2 s
ON
OFF
OFF
5 s
ON
OFF
ON
10 s
ON
ON
OFF
30 s
ON
ON
ON
60 s
LED Colour
SW1.7
SW1.8
OFF
OFF
No light
OFF
ON
Red
ON
OFF
Green
ON
ON
Yellow
