M4200 - User manual
Revision: 07.03.2017 Page 16
Set button
The set button is positioned on the rear of the alarm monitor, below the dip switches.
This push button is used for accept of rotary and dip switch settings. Set button is related to the rotary switch,
which means that all dip switch settings made, in the selected position of the rotary switch, will be saved
when the set button is pushed.
IMPORTANT
It is very important to check the position of all 16 dip switches before set button is pushed.
Acknowledge LED
Acknowledge LED is positioned on the rear of the alarm monitor, beside the save button.
When the rotary switch is in programming mode (Position 1 - 9) the LED gives a constant red light.
When set button is pushed and held down, the LED will flash 2 times and change into green light until set
button is released. Green light indicates that saving the settings done by set button is accepted.
