Selco M4200 - Alarm 2 (Output Relay 2); Siren (Relay); Output 1 - 4

M4200 - User manual
Revision: 07.03.2017 Page 30
Parameter
Command
Description
Alarm 2 (output relay 2)
WRITE ALM1 RELAY2 OFF
Alarm 2 (output relay 2) is NOT active when alarm on input 1 is ON
WRITE ALM2 RELAY2 OFF
Alarm 2 (output relay 2) is NOT active when alarm on input 2 is ON
WRITE ALM3 RELAY2 OFF
Alarm 2 (output relay 2) is NOT active when alarm on input 3 is ON
WRITE ALM4 RELAY2 OFF
Alarm 2 (output relay 2) is NOT active when alarm on input 4 is ON
WRITE ALM5 RELAY2 OFF
Alarm 2 (output relay 2) is NOT active when alarm on input 5 is ON
WRITE ALM6 RELAY2 OFF
Alarm 2 (output relay 2) is NOT active when alarm on input 6 is ON
WRITE ALM7 RELAY2 OFF
Alarm 2 (output relay 2) is NOT active when alarm on input 7 is ON
WRITE ALM8 RELAY2 OFF
Alarm 2 (output relay 2) is NOT active when alarm on input 8 is ON
WRITE ALM1 RELAY2 ON
Alarm 2 (output relay 2) is active when alarm on input 1 is ON
WRITE ALM2 RELAY2 ON
Alarm 2 (output relay 2) is active when alarm on input 2 is ON
WRITE ALM3 RELAY2 ON
Alarm 2 (output relay 2) is active when alarm on input 3 is ON
WRITE ALM4 RELAY2 ON
Alarm 2 (output relay 2) is active when alarm on input 4 is ON
WRITE ALM5 RELAY2 ON
Alarm 2 (output relay 2) is active when alarm on input 5 is ON
WRITE ALM6 RELAY2 ON
Alarm 2 (output relay 2) is active when alarm on input 6 is ON
WRITE ALM7 RELAY2 ON
Alarm 2 (output relay 2) is active when alarm on input 7 is ON
WRITE ALM8 RELAY2 ON
Alarm 2 (output relay 2) is active when alarm on input 8 is ON
Siren (relay)
WRITE ALM1 SIREN ON
Siren is active when alarm on input 1 is ON
WRITE ALM2 SIREN ON
Siren is active when alarm on input 2 is ON
WRITE ALM3 SIREN ON
Siren is active when alarm on input 3 is ON
WRITE ALM4 SIREN ON
Siren is active when alarm on input 4 is ON
WRITE ALM5 SIREN ON
Siren is active when alarm on input 5 is ON
WRITE ALM6 SIREN ON
Siren is active when alarm on input 6 is ON
WRITE ALM7 SIREN ON
Siren is active when alarm on input 7 is ON
WRITE ALM8 SIREN ON
Siren is active when alarm on input 8 is ON
WRITE ALM1 SIREN OFF
Siren is NOT active when alarm on input 1 is ON
WRITE ALM2 SIREN OFF
Siren is NOT active when alarm on input 2 is ON
WRITE ALM3 SIREN OFF
Siren is NOT active when alarm on input 3 is ON
WRITE ALM4 SIREN OFF
Siren is NOT active when alarm on input 4 is ON
WRITE ALM5 SIREN OFF
Siren is NOT active when alarm on input 5 is ON
WRITE ALM6 SIREN OFF
Siren is NOT active when alarm on input 6 is ON
WRITE ALM7 SIREN OFF
Siren is NOT active when alarm on input 7 is ON
WRITE ALM8 SIREN OFF
Siren is NOT active when alarm on input 8 is ON
Output 1 - 4
WRITE ALM1 OUTPUT1 OFF
Open collector output 1 is NOT active when alarm on input 1 is ON
It is possible to replace
WRITE ALM2 OUTPUT1 OFF
Open collector output 1 is NOT active when alarm on input 2 is ON
“OUTPUT1” with
WRITE ALM3 OUTPUT1 OFF
Open collector output 1 is NOT active when alarm on input 3 is ON
“OUTPUT2”,
WRITE ALM4 OUTPUT1 OFF
Open collector output 1 is NOT active when alarm on input 4 is ON
“OUTPUT3” or
WRITE ALM5 OUTPUT1 OFF
Open collector output 1 is NOT active when alarm on input 5 is ON
“OUTPUT4”
WRITE ALM6 OUTPUT1 OFF
Open collector output 1 is NOT active when alarm on input 6 is ON
WRITE ALM7 OUTPUT1 OFF
Open collector output 1 is NOT active when alarm on input 7 is ON
WRITE ALM8 OUTPUT1 OFF
Open collector output 1 is NOT active when alarm on input 8 is ON
WRITE ALM1 OUTPUT1 ON
Open collector output 1 is active when alarm on input 1 is ON
WRITE ALM2 OUTPUT1 ON
Open collector output 1 is active when alarm on input 2 is ON
WRITE ALM3 OUTPUT1 ON
Open collector output 1 is active when alarm on input 3 is ON
WRITE ALM4 OUTPUT1 ON
Open collector output 1 is active when alarm on input 4 is ON
WRITE ALM5 OUTPUT1 ON
Open collector output 1 is active when alarm on input 5 is ON
WRITE ALM6 OUTPUT1 ON
Open collector output 1 is active when alarm on input 6 is ON
WRITE ALM7 OUTPUT1 ON
Open collector output 1 is active when alarm on input 7 is ON
WRITE ALM8 OUTPUT1 ON
Open collector output 1 is active when alarm on input 8 is ON
