Select Engineered Systems Select Gate 1A - Changing Select Gate Light Bulb

SELECT GATE SG-1A V1.X
SELECT ENGINEERED SYSTEMS 11/01 17
SIDE
VIEW
3.1.9 CHANGING SELECT GATE BULB
The Select Gate has two light bulbs, one on either side of the Select Gate
front panel. These are Chicago Miniature Lamp type 161 light bulbs. They are
rated at 14 volts at 190 ma. each. They are run at a lesser voltage to increase
their operational life-time. These lamps may be replaced with similar equivalents
from national electronics chain stores or automotive supply stores. They also are
available from SES (part # 305T3R25161).
To change the light bulb, pull the light bulb out of it's socket by pulling from the
back plate toward the face plate. Insert the new light bulb by pressing down into the
socket, until the bulb seats.
It is recommended that both light bulbs be replaced whenever a light bulb is needed.
