Sena 30K - Wired Boom Microphone

Helmet
Installation
Using the
Glued Surface
Mounting
Adapter
Switching the
Microphone
Earbuds
External Mesh
Intercom
Antenna
30K Motorcycle Bluetooth Communication System | 18
2. InstallIng the
headset on
Your helmet
MENU
2.3.1 Wired Boom Microphone
When installing the included wired boom
microphone, place the hook and loop
fastener at the end of the boom microphone
between the internal helmet cheek pad and
the internal wall of the helmet shell. The
boom microphone should be mounted so it is
facing close to your mouth when you wear the
helmet.
Speaker Port
Microphone Port
2.3.2 Wired Microphone
In case of the wired microphone, attach the
enclosed hook and loop fastener for the wired
microphone to the inside of the chin guard for
full-face helmets. Place the wired microphone
on the hook and loop fastener and connect it
to the connector of the clamp unit.
Speaker Port
Microphone Port
