Pos. No. Part No Quantity Cut-Off Machine;
Engine and Drive Unit
1*
S-21-00-676 1 Engine
2
S-80-73-302 1 Cylinder cover
3
S-00-30-108 1 Washer
4
S-00-18-336 3 Screw
5 S-23-00-447 1 Generator
6
S-00-13-287 3 Screw
8
S-24-00-328 1 Flywheel
9
S-00-72-145 1 Circlip
10 S-00-20-145 1 Nut
11
S-23-00-696 1 Ignition
12
S-00-30-101 1 Washer
13
S-00-18-327 3 Screw
14
S-00-18-334 1 Screw
15
S-35-00-483 1 Clutch drum
16
S-60-42-850 1 Washer
17
S-35-00-470 1 Centrifugal clutch incl. (-> 17, 17a
17a
S-00-73-470 3 Clutch spring <-)
18
S-00-33-429 1 Spacer tube
19
S-00-55-161 1 Circlip
Pos. No. Part No Quantity Cut-Off Machine;
Engine and Drive Unit
19a
S-60-45-498 1 Clutch cover disc
20 S-60-63-324 1 Manifold
21
S-60-43-137 1 Suction hose
22
S-00-73-451 1 Clamp
25
S-00-66-335 2 Grommet
26
S-00-66-678 2 Clamp
38
S-60-73-541 1 Air guide
39*
S-26-00-257 1 Starter
40
S-00-18-337 4 F.h. screw
45
S-00-64-245 1 Impulse hose
74
S-00-57-114 1 Belt
75 S-60-73-710 1 Cover clutch
76
S-00-18-460 3 Screw
77*
S-33-00-114 1 Drive unit
78*
S-61-00-338 1 Cover drive unit
79
S-00-24-106 2 Nut
83 S-60-31-810 1 Adapter 1"
HOW TO CHANGE
SPARK PLUG
HOW TO CHANGE
AIR FILTER
HOW TO CHANGE
carburetor
HOW TO CHANGE
PISTON & CYLINDER
HOW TO CHANGE
DECOMPRESSION
Valve
HOW TO CHANGE
STARTER
SENCORE S8100 CUT-OFF SAW MANUAL 39
