Sencore S8100 | Cut-Off Machine Grip Unit Parts
61 S-80-74-772 1 Screen 62 S-00-13-285 2 Screw 63 S-25-00-771 1 Screen insert 64 S-25-00-793 1
Mainlter
64 S-25-00-794 10 Mainlter 64 S-25-00-795 20 Mainlter 65 S-25-00-510 1 Filter cover
66* S-63-00-274 3 Spring support
67 S-60-74-832 1 Clamp 68 S-00-10-264 1 Screw
69* S-61-00-240 1 Cover
70 S-00-18-338 2 F.h. screw 71 S-00-18-389 2 F.h. screw 72 S-60-74-453 1 Cover 73 S-00-18-361 5 Screw 80 S-67-00-121 1 Oil strainer 81 S-27-00-135 1 Filter fuel pick-up
83* S-00-65-324 1 Connection
84 S-00-65-325 1 Hose coupling
Pos. No. Part No. Quantity Grip Unit
Pos. No. Part No. Quantity Grip Unit
23* S-63-00-273 1 Support
24* S-63-00-275 1 Support
27* S-61-00-497 1 Grip
28 S-27-00-240 1 "Tank lid incl. (-> 28, 29"
29 S-00-62-347 1 O-ring <-)
30 S-27-00-241 1 "Tank lid incl. (-> 30, 31"
31 S-00-62-347 1 O-ring <-)
33 S-60-74-542 1 Flange ring 34 S-80-63-249 1 Cable grommet
35 S-00-18-355 2 Screw 36 S-00-66-429 1 Grommet 37 S-00-10-362 1 F.h. screw 41 S-00-64-328 2 Spacer tube 42 S-20-61-444 1 Gasket carburettor 43 S-20-36-285 1 Throttle linkage 44 S-23-00-692 1 Carburetor 45 S-05-10-796 1 Repair kit - Carburetor
46 S-00-64-246 1 Hose
47* S-23-00-871 1 Expansion chamber
48 S-00-34-152 2 Circlip 49 S-00-18-455 2 Screw 50 S-23-00-872 1 Suction elbow
51 S-00-18-274 4 Lens head screw
53 S-00-18-336 4 Screw 54 S-00-18-335 4 Screw 55 S-00-72-140 2 Disc spring
56 S-80-74-746 1 Snorkel right 57 S-80-74-747 1 Snorkel left
58* S-61-00-486 1 Console
59 S-60-74-870 1 Filter housing 60 S-00-28-156 4 Speed nut m5
40 SENCORE S8100 CUT-OFF SAW MANUAL
