Sepura SC21 Series User Manual

NOTE: Talkgroups in the Smart Call Folder-1 or Smart Call Folder-2 folders can
only be accessed when the appropriate Smart Call mode has been selected from the
Speech Call Settings screen or by using a soft key. (See Smart Calls on page62.)
Standard talkgroup selection
1.
From the Home Screen, press the Groups key. The current selected folder and talkgroup
appear in the talkgroup selection box.
2. If you want to change to another talkgroup within the same folder, simply enter the number of
the talkgroup, or select the All Folder which contains all the talkgroups and enter the number
of the talkgroup.
3. Use the Left and Right navigation keys to move between folders at the same level. Use the
Up and Down navigation keys to move between the folder levels (sub-folders).
4.
Rotate the Navi-knob to scroll through the talkgroups within the currently selected folder. The
directional arrows under the talkgroup name indicate the rotational direction of the Navi-
knob.
5.
Press the Select context key to attach to the talkgroup.
Customised talkgroup selection
When the radio is customised to use the Left and Right navigation keys for talkgroup selection:
1.
From the Home Screen, press the Left or Right navigation keys. The current selected folder
and previous/next talkgroup folders appear in the talkgroup selection box. If customised you
can scroll through the talkgroups continuously.
40 SC21 Series hand-portable radio

Sepura SC21 Series Specifications

General

IP Rating	IP54
Operating Temperature	-20°C to +55°C
Channel Spacing	25 kHz
Ingress Protection	IP54
Channels	Up to 2000
Frequency Bands	380-430 MHz, 806-870 MHz
Battery Life	Up to 14 hours
RF Power Output	1W
TETRA Air Interface	ETSI EN 300 392-2
