SCORPIO 38’ - 45’ - DOCUMENTATION - Weights of the cranes
Version 1.02 May 27, 2022
96
9.2 WEIGHTS OF THE CRANES
COMMONLY USED WEIGHTS:
DETAILED WEIGHTS OF THE CRANE:
SCORPIO 45'
SCORPIO 38'
Empty arm
691kg. / 1523.3 lbs.
533kg. / 1175 lbs.
Counterweights support
80kg. / 176.3 lbs.
84kg. / 185.1 lbs.
Leveling head
15kg. / 33 lbs.
15kg. / 33 lbs.
Power unit
7kg. / 15.4 lbs.
7kg. / 15.4 lbs.
Leveling head cable & Scorpio head
cable
11kg. / 24.2 lbs.
10kg. / 22 lbs.
Rest of cables & hand unit
3kg. / 6.6 lbs.
3kg. / 6.6 lbs.
Electronic box
54kg. / 119 lbs.
54kg. / 119 lbs.
Protection bars & upper operation bars
29kg. / 63.9 lbs.
25kg. / 55.1 lbs.
Rear operation bars (lower operation
bars)
7,5kg. / 16.5 lbs.
7,5kg. / 16.5 lbs.
Fulcrum
108kg. / 238 lbs.
93kg. / 205 lbs.
Column
148kg. / 326.2 lbs.
113kg. / 249.1 lbs.
Empty dolly (chassis)
186kg. / 410 lbs.
219kg. / 482.8 lbs.
Leveling jack on dolly 38'
-
6kg. / 13.2 lbs.
Straps
7,5kg. / 16.5 lbs.
7,5kg. / 16.5 lbs.
Locking screws for weights (per side)
1,6kg. / 3.5 lbs.
1,6kg. / 3.5 lbs.
Wheels (x1)
18kg. / 39.6 lbs.
18kg. / 39.6 lbs.
Leveling Jacks for wheels (x1)
9kg. / 19.8 lbs.
9kg. / 19.8 lbs.
Travelling wheels (x1)
4kg. / 8.8 lbs.
4kg. / 8.8 lbs.
Steering wheel for leveling jack (x1)
3kg. / 6.6 lbs.
3kg. / 6.6 lbs.
Steering handle (x1)
3kg. / 6.6 lbs.
3kg. / 6.6 lbs.
SCORPIO 45'
SCORPIO 38'
Crane assembled (truck load)
1486,2 kg. / 3276.5 lbs.
1316,2kg. / 2901 lbs.
Max. Weight of the crane
(Max payload)
2473,1 kg. / 5452 lbs.
2123,1kg. / 4680.6 lbs.
Column + Fulcrum + Dolly
(4 wheels & 2 steering handle)
520kg. / 1146 lbs.
503kg. / 1109 lbs.
Empty arm
691kg. / 1523.3 lbs.
533kg. / 1175 lbs.
